AUTOCOMP is extremely fine in the 38 Super, 9mm, 45 ACP and 40 S&W race guns. It’s just the perfect burning speed to feed the compensators with a higher volume of gas. With AUTOCOMP competitors get off faster shots with minimal muzzle flash, it’s a winner.
| Shape | Color | Perforation | Diameter min | Diameter max | Length/thick. min | Length/thick. max | Manufacturer |
|---|---|---|---|---|---|---|---|
Ladedata som finnes på hjemmesidene til Evje PK er KUN ment som en veiledning! Ladedata skal alltid verifiseres mot kjente kilder (kruttprodusenter, ladebøker o.l.)
Data funnet på våre hjemmesider brukes på eget ansvar, og Evje Pistolklubb fratar seg alt ansvar for feil bruk av, eller skrivefeil i oppgitte data.
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
 | 71 | Sierra FMJ | 2.7 | 879 | starting load; 13,900 cup |
| 71 | Sierra FMJ | 3.0 | 937 | maximum load; 14,800 cup |
| Hodgdon Pistol Data case: Winchester; barrel length: 4"; twist: 1:16"; trim length: .675"; primer: Federal 100M; bullet diam.: .312"; COL: .978"; NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
 | 77 | Cast LFP | 3.0 | 773 | start load; COL: 1.335"; 6,700 cup; bullet diam.: .314" |
| 77 | Cast LFP | 4.0 | 1016 | max load; COL: 1.335"; 12,800 cup; bullet diam.: .314" |
| 83 | Berry's Bullets HBWC | 3.3 | 856 | start load; COL: 1.095"; 12,500 cup; bullet diam.: .314" |
| 83 | Berry's Bullets HBWC | 4.3 | 1138 | max load; COL: 1.095"; 20,700 cup; bullet diam.: .314" |
| 85 | Hornady HP | 4.2 | 1037 | start load; COL: 1.290"; 15,500 cup; bullet diam.: .312" |
| 85 | Hornady HP | 4.6 | 1114 | max load; COL: 1.290"; 19,200 cup; bullet diam.: .312" |
| 90 | Sierra JHP | 4.0 | 957 | start load; COL: 1.340"; 15,700 cup; bullet diam.: .312" |
| 90 | Sierra JHP | 4.5 | 1082 | max load; COL: 1.340"; 20,300 cup; bullet diam.: .312" |
| 90 | Hornady LSWC | 3.4 | 874 | start load; COL: 1.350"; 10,400 cup; bullet diam.: .314" |
| 90 | Hornady LSWC | 3.9 | 997 | max load; COL: 1.350"; 14,500 cup; bullet diam.: .314" |
| 100 | Speer JHP | 3.7 | 867 | start load; COL: 1.345"; 15,200 cup; bullet diam.: .312" |
| 100 | Speer JHP | 4.2 | 964 | max load; COL: 1.345"; 18,900 cup; bullet diam.: .312" |
| Hodgdon Pistol Data Case: Federal; twist: 1:16"; primer: Federal 100, Small Pistol; barrel length: 5"; trim length: 1.070". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 115 | Oregon Trail FP BB | 4.5 | 894 | overall loaded length (inches): 1.560 |
| 115 | Oregon Trail FP BB | 5.0 | 952 | overall loaded length (inches): 1.560 |
| (Standard Pressure) Handloads All loads were fired from a 4.75-inch barreled Colt Single Action Army. Maximum pressure for these loads is 16,000 CUP. Starline cases and Winchester Small Rifle primers were used throughout. Bullet diameter: .312 to .314 inch. Maximum overall loaded length: 1.592 inches; maximum case length: 1.315 inches; trim-to length: 1.305 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 77 | Cast LFP | 5.9 | 1251 | start load; bullet diam.: .314"; COL: 1.460"; 17,700 psi |
| 77 | Cast LFP | 6.7 | 1393 | max load; bullet diam.: .314"; COL: 1.460; 21,900 psi |
| 85 | Hornady XTP | 6.3 | 1387 | start load; COL: 1.450"; 32,700 psi |
| 85 | Hornady XTP | 7.0 | 1518 | max load; COL: 1.450"; 42,100 psi |
 | 90 | Cast LRNFP | 5.5 | 1210 | start load; COL: 1.460"; 19,900 psi |
| 90 | Cast LRNFP | 6.3 | 1348 | max load; COL: 1.460"; 28,700 psi |
| 90 | Sierra JHC | 6.4 | 1337 | start load; COL: 1.460"; 29,200 psi |
| 90 | Sierra JHC | 7.2 | 1493 | max load; COL: 1.460"; 42,900 psi |
| 100 | Hornady XTP | 5.5 | 1190 | start load; COL: 1.450"; 32,500 psi |
| 100 | Hornady XTP | 6.2 | 1328 | max load; COL: 1.450"; 41,400 psi |
| 115 | MEI LRNFP | 4.7 | 1062 | start load; COL: 1.460"; 22,100 psi |
| 115 | MEI LRNFP | 5.5 | 1194 | max load; COL: 1.460"; 33,500 psi |
| Hodgdon Data Case: Federal; barrel length: 5"; twist: 1:16"; trim length: 1.200"; primer: Federal 200; bullet diam.: .312 (except where otherwise specified in remarks). NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 85 | Hornady HP XTP | 6.1 | 1281 | |
| 85 | Hornady HP XTP | 6.4 | 1341 | |
| 85 | Hornady HP XTP | 6.7 | 1401 | |
| 85 | Hornady HP XTP | 7.0 | 1460 | maximum load |
| 100 | Hornady HP XTP | 5.5 | 1145 | |
| 100 | Hornady HP XTP | 5.8 | 1219 | |
| 100 | Hornady HP XTP | 6.1 | 1292 | maximum load |
| Using Hornady Bullets Gun: USFA Sparrow Hawk; barrel length: 7 1/2 inches; case: Federal Cartridge; primer: Federal #205; bullet diameter: .312"; COAL: 1.450"; maximum COAL: 1.475"; maximum case length: 1.200"; trim to length: 1.190". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 115 | Oregon Trail RNFP | 4.0 | 941 | overall loaded length (inches): 1.468 |
| 115 | Oregon Trail RNFP | 4.5 | 1019 | overall loaded length (inches): 1.468 |
| 115 | Oregon Trail RNFP | 5.0 | 1121 | overall loaded length (inches): 1.468 |
| 115 | Oregon Trail RNFP | 5.5 | 1199 | overall loaded length (inches): 1.468 |
| Handloads A Ruger Single-Seven with a 7 1/2-inch barrel was used to test fire these loads. Federal cases and CCI 500 primers were used throughout. Bullet diameter: .312 and .313 inch; maximum case length: 1.200 inches; trim to length: 1.195 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 110 | Hornady XTP | 7.7 | 1483 | start load; COL: 1.590"; 23,900 psi |
| 110 | Hornady XTP | 8.6 | 1631 | max load; COL: 1.590"; 32,900 psi |
| 125 | Hornady XTP | 7.5 | 1352 | start load; COL: 1.590"; 26,900 psi |
| 125 | Hornady XTP | 8.2 | 1455 | max load; COL: 1.590"; 31,700 psi |
| 125 | MEI Cast LRNFP | 6.5 | 1311 | start load; bullet diam.: .358"; COL: 1.580"; 20,600 psi |
| 125 | MEI Cast LRNFP | 7.5 | 1456 | max load; bullet diam.: .358"; COL: 1.580"; 27,500 psi |
| 130 | MEI Cast LRNFP | 6.0 | 1216 | start load; bullet diam.: .358"; COL: 1.580"; 18,700 psi |
| 130 | MEI Cast LRNFP | 7.3 | 1392 | max load; bullet diam.: .358"; COL: 1.580"; 25,000 psi |
| 140 | Hornady XTP | 6.5 | 1164 | start load; COL: 1.590"; 22,000 psi |
| 140 | Hornady XTP | 7.6 | 1346 | max load; COL: 1.590"; 32,400 psi |
| 140 | Hornady FTX | 5.0 | 1038 | start load; COL: 1.600"; 22,500 psi |
| 140 | Hornady FTX | 6.3 | 1279 | max load; COL: 1.600"; 33,200 psi |
| 146 | Speer JHP | 6.4 | 1193 | start load; COL: 1.535"; 26,000 psi |
| 146 | Speer JHP | 7.1 | 1288 | max load; COL: 1.535"; 32,300 psi |
| 148 | Hornady LHBWC | 4.0 | 943 | start load; bullet diam.: .358"; COL: 1.290"; 18,000 psi |
| 148 | Hornady LHBWC | 4.7 | 1064 | max load; bullet diam.: .358"; COL: 1.290"; 24,300 psi |
| 158 | Hornady XTP | 6.2 | 1058 | start load; COL: 1.580"; 25,700 psi |
| 158 | Hornady XTP | 7.0 | 1181 | max load; COL: 1.580"; 33,200 psi |
| 158 | MEI Cast LSWC | 5.0 | 1025 | start load; bullet diam.: .358"; COL: 1.620"; 17,600 psi |
| 158 | MEI Cast LSWC | 6.5 | 1237 | max load; bullet diam.: .358"; COL: 1.620"; 27,000 psi |
| 180 | Nosler Part | 5.3 | 869 | start load; COL: 1.575"; 27,700 psi |
| 180 | Nosler Part | 5.9 | 997 | max load; COL: 1.575"; 33,700 psi |
| Hodgdon Data Case: Winchester; barrel length: 10"; twist: 1:18.75"; trim length: 1.285"; primer: Winchester SPM; bullet diam.: .357" (except where otherwise specified in remarks). NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 90 | Cast LRNFP | 3.7 | 790 | start load; bullet diam.: .359"; COL: 1.325"; 7,500 psi |
| 90 | Cast LRNFP | 5.1 | 1089 | max load; bullet diam.: .359"; COL: 1.325"; 10,800 psi |
| 110 | Hornady XTP | 5.8 | 860 | start load; bullet diam.: .357"; COL: 1.455"; 11,700 psi |
| 110 | Hornady XTP | 6.4 | 1101 | max load; bullet diam.: .357"; COL: 1.455"; 16,000 psi |
| 125 | Hornady XTP | 5.7 | 985 | start load; bullet diam.: .357"; COL: 1.455"; 13,600 psi |
| 125 | Hornady XTP | 6.2 | 1068 | max load; bullet diam.: .357"; COL: 1.455"; 16,500 psi |
 | 125 | Cast LRNFP | 5.7 | 1048 | start load; bullet diam.: .358"; COL: 1.445"; 7,300 psi |
| 125 | Cast LRNFP | 6.2 | 1139 | max load; bullet diam.: .358"; COL: 1.445"; 10,800 psi |
| 130 | MEI Cast LRNFP | 5.5 | 981 | start load; bullet diam.: .358"; COL: 1.460"; 13,600 psi |
| 130 | MEI Cast LRNFP | 6.0 | 1072 | max load; bullet diam.: .358"; COL: 1.460"; 15,800 psi |
| 140 | Hornady XTP | 5.0 | 880 | start load; bullet diam.: .357"; COL: 1.455"; 14,400 psi |
| 140 | Hornady XTP | 5.5 | 989 | max load; bullet diam.: .357"; COL: 1.455"; 16,600 psi |
| 140 | Hornady Cowboy | 5.2 | 971 | start load; bullet diam.: .358"; COL: 1.450"; 14,000 psi |
| 140 | Hornady Cowboy | 5.8 | 1055 | max load; bullet diam.: .358"; COL: 1.450"; 16,100 psi |
| 146 | Speer JHP | 4.6 | 796 | start load; bullet diam.: .357"; COL: 1.370"; 13,100 psi |
| 146 | Speer JHP | 5.0 | 881 | max load; bullet diam.: .357"; COL: 1.370"; 14,700 psi |
| 148 | Hornady LHBWC | 3.7 | 820 | start load; bullet diam.: .358"; COL: 1.160"; 14,100 psi |
| 148 | Hornady LHBWC | 4.1 | 881 | max load; bullet diam.: .358"; COL: 1.160"; 15,200 psi |
| 158 | Hornady XTP | 4.5 | 751 | start load; bullet diam.: .357"; COL: 1.455"; 14,000 psi |
| 158 | Hornady XTP | 4.9 | 865 | max load; bullet diam.: .357"; COL: 1.455"; 16,800 psi |
 | 158 | Cast LSWC | 4.8 | 870 | start load; bullet diam.: .358"; COL: 1.475"; 14,300 psi |
| 158 | Cast LSWC | 5.3 | 984 | max load; bullet diam.: .358"; COL: 1.475"; 16,800 psi |
| 170 | Sierra JHC | 4.3 | 736 | start load; bullet diam.: .357"; COL: 1.450"; 14,300 psi |
| 170 | Sierra JHC | 4.8 | 820 | max load; bullet diam.: .357"; COL: 1.450"; 16,000 psi |
| Hodgdon Pistol Data Case: Winchester; twist: 1:18.75"; primer: Winchester SP, Small Pistol; barrel length: 7.7"; trim length: 1.145". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 110 | Hornady XTP | 7.0 | 1228 | 17,400 psi |
| 125 | Hornady XTP | 6.4 | 1073 | 17,600 psi |
| 140 | Hornady XTP | 5.7 | 1031 | 18,000 psi |
| 146 | Speer JHP | 5.2 | 957 | COL: 1.370"; 17,500 psi |
| 158 | Hornady XTP | 5.0 | 885 | 17,000 psi |
| 170 | Sierra JHC | 4.8 | 844 | COL: 1.450"; 18,200 psi |
| +P Hodgdon Pistol Data Maximum Loads case: Winchester; barrel length: 7.7"; twist: 1:18.75"; trim length: 1.145"; primer: Winchester SP; bullet diam.: .357"; COL: 1.455" (except where otherwise specified in remarks); NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 110 | Hornady XTP | 6.4 | 830 | case: Hornady; primer: WSP |
| 110 | Hornady XTP (+P) | 7.0 | 924 | case: Hornady; primer: WSP |
| 125 | Hornady XTP | 6.2 | 831 | case: Hornady; primer: WSP |
| 125 | Hornady XTP (+P) | 6.4 | 873 | case: Hornady; primer: WSP |
| S&W Model 36 Chiefs Special Hodgdon Data S&W Model 36 Chiefs Special, 1.875-in. barrel. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 90 | Sierra JHP | 6.6 | 1311 | start load; COL: 1.180"; 27,100 cup |
| 90 | Sierra JHP | 7.2 | 1388 | max load; COL: 1.180"; 32,500 cup |
| 95 | Barnes TAC-XP | 5.9 | 1279 | start load; COL: 1.255"; 26,900 cup |
| 95 | Barnes TAC-XP | 6.6 | 1398 | max load; COL: 1.255"; 31,700 cup |
| 115 | LRN | 6.0 | 1178 | start load; bullet diam.: .356"; COL: 1.250"; 26,400 cup |
| 115 | LRN | 6.5 | 1246 | max load; bullet diam.: .356"; COL: 1.250"; 32,000 cup |
| 115 | Hornady XTP | 5.7 | 1152 | start load; COL: 1.245"; 27,400 cup |
| 115 | Hornady XTP | 6.2 | 1238 | max load; COL: 1.245"; 32,000 cup |
| 124 | Berry's Bullets HBRN TP | 5.7 | 1126 | start load; bullet diam.: .356"; COL: 1.250"; 25,100 cup |
| 124 | Berry's Bullets HBRN TP | 6.3 | 1222 | max load; bullet diam.: .356"; COL: 1.250"; 32,100 cup |
| 125 | Hornady HAP | 5.5 | 1148 | start load; bullet diam.: .356"; COL: 1.210"; 24,800 cup |
| 125 | Hornady HAP | 6.0 | 1240 | max load; bullet diam.: .356"; COL: 1.210"; 31,200 cup |
| 125 | Sierra FMJ | 5.7 | 1067 | start load; COL: 1.275"; 26,200 cup |
| 125 | Sierra FMJ | 6.2 | 1173 | max load; COL: 1.275"; 31,400 cup |
| 125 | Cast LCN | 5.5 | 1109 | start load; bullet diam.: .356"; COL: 1.230"; 26,300 cup |
| 125 | Cast LCN | 6.1 | 1174 | max load; bullet diam.: .356"; COL: 1.230"; 31,700 cup |
| 130 | Berry's Bullets RN | 5.3 | 1035 | start load; COL: 1.270"; 25,800 cup |
| 130 | Berry's Bullets RN | 5.8 | 1109 | max load; COL: 1.270"; 31,100 cup |
| 135 | LRN | 5.3 | 1065 | start load; bullet diam.: .356"; COL: 1.275"; 25,400 cup |
| 135 | LRN | 5.8 | 1139 | max load; bullet diam.: .356"; COL: 1.275"; 31,400 cup |
| 147 | Hornady XTP | 5.0 | 943 | start load; COL: 1.260"; 25,300 cup |
| 147 | Hornady XTP | 5.5 | 1056 | max load; COL: 1.260"; 32,900 cup |
| Hodgdon Data Case: Remington; twist: 1:16"; primer: Remington 1 1/2, Small Pistol; barrel length: 5"; trim length: .895"; bullet diam.: .355" (except where otherwise specified in remarks). | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 115 | HDY | 5.7 | 1152 | starting load; 27,400 cup |
| 115 | HDY | 6.2 | 1238 | maximum load; 32,000 cup |
| 115 | LRN | 6.0 | 1178 | starting load; 26,400 cup |
| 115 | LRN | 6.5 | 1246 | maximum load; 32,000 cup |
| 125 | LCN | 5.5 | 1109 | starting load; 26,300 cup |
| 125 | LCN | 6.1 | 1174 | maximum load; 31,700 cup |
| 125 | SIE | 5.7 | 1067 | starting load; 26,200 cup |
| 125 | SIE | 6.2 | 1173 | maximum load; 31,400 cup |
| 130 | SIE | 5.6 | 1042 | starting load; 24,500 cup |
| 130 | SIE | 6.1 | 1144 | maximum load; 31,900 cup |
| 135 | LRN | 5.3 | 1065 | starting load; 25,400 cup |
| 135 | LRN | 5.8 | 1139 | maximum load; 31,400 cup |
| 147 | HDY | 5.0 | 943 | starting load; 25,300 cup |
| 147 | HDY | 5.5 | 1056 | maximum load; 32,900 cup |
| Winchester AutoComp Data | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 90 | Hornady JHP | 4.1 | 893 | starting load; COL: .955"; 11,200 cup |
| 90 | Hornady JHP | 4.5 | 1012 | maximum load; COL: .955"; 15,000 cup |
| 95 | Speer FMJ | 3.9 | 816 | starting load; COL: .970"; 10,600 cup |
| 95 | Speer FMJ | 4.3 | 937 | maximum load; COL: .970"; 14,100 cup |
| 100 | Hornady FMJ | 3.8 | 822 | starting load; COL: .980"; 11,000 cup |
| 100 | Hornady FMJ | 4.2 | 934 | maximum load; COL: .980"; 14,400 cup |
| Hodgdon Pistol Data case: Remington; barrel length: 3.75"; twist: 1:16"; trim length: .675"; primer: CCI 500; bullet diam.: .355"; NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 90 | Sierra JHP | 4.5 | 1003 | extreme spread (fps): 56 |
| 95 | Sierra FMJ | 4.3 | 880 | extreme spread (fps): 89 |
| 100 | Speer JHP | 4.0 | 912 | extreme spread (fps): 43 |
| Selected Maximum Handloads All loads assembled in Starline brass with CCI Small Pistol primers. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
 | 90 | Hornady HP-XTP | 3.9 | 908 | |
| 90 | Hornady HP-XTP | 4.0 | 939 | |
| 90 | Hornady HP-XTP | 4.2 | 1000 | maximum load |
| Using Hornady Bullets Gun: Walther PPK/S; barrel length: 3 1/4 inches; case: Starline; primer: Winchester WSP; bullet diameter: .355"; maximum COAL: .980"; maximum case length: .680"; trim to length: .675"; COAL: .965". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 90 | Hornady XTP | 4.2 | 976 | |
| 90 | Hornady XTP | 4.5 | 1026 | |
| 95 | Speer TMJ | 4.0 | 839 | |
| 95 | Speer TMJ | 4.3 | 938 | |
| 95 | Cast LRN | 4.0 | 885 | |
| 95 | Cast LRN | 4.3 | 938 | |
| 100 | Hornady FMJ | 3.9 | 861 | |
| 100 | Hornady FMJ | 4.2 | 930 | |
| Handloads Hodgdon Data Case: Starline; primer: CCI 500. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 135 | Nosler JHP | 8.0 | 1236 | start load; COL: 1.125"; 26,600 psi |
| 135 | Nosler JHP | 8.8 | 1342 | max load; COL: 1.125"; 32,700 psi |
| 140 | Barnes TAC-XP | 5.9 | 1089 | start load; COL: 1.135"; 27,400 psi |
| 140 | Barnes TAC-XP | 6.3 | 1154 | max load; COL: 1.135"; 33,000 psi |
| 150 | Nosler JHP | 6.6 | 1105 | start load; COL: 1.125"; 24,300 psi |
| 150 | Nosler JHP | 7.3 | 1220 | max load; COL: 1.125"; 32,100 psi |
| 155 | Hornady XTP | 7.0 | 1109 | start load; COL: 1.125"; 25,800 psi |
| 155 | Hornady XTP | 7.8 | 1223 | max load; COL: 1.125"; 33,800 psi |
| 155 | Berry's Bullets FP | 6.7 | 1091 | start load; COL: 1.125"; 24,800 psi |
| 155 | Berry's Bullets FP | 7.3 | 1200 | max load; COL: 1.125"; 31,600 psi |
| 165 | Sierra JHP | 6.5 | 1037 | start load; COL: 1.125"; 25,600 psi |
| 165 | Sierra JHP | 7.1 | 1124 | max load; COL: 1.125"; 31,500 psi |
| 165 | Berry's Bullets FP | 6.3 | 1051 | start load; COL: 1.125"; 25,900 psi |
| 165 | Berry's Bullets FP | 7.0 | 1171 | max load; COL: 1.125"; 33,300 psi |
| 180 | Berry's Bullets FP | 5.7 | 971 | start load; COL: 1.125"; 26,700 psi |
| 180 | Berry's Bullets FP | 6.2 | 1060 | max load; COL: 1.125"; 33,000 psi |
| 180 | Hornady XTP | 5.8 | 975 | start load; COL: 1.125"; 27,700 psi |
| 180 | Hornady XTP | 6.3 | 1053 | max load; COL: 1.125"; 33,200 psi |
| 200 | Hornady XTP | 4.8 | 838 | start load; COL: 1.125"; 27,900 psi |
| 200 | Hornady XTP | 5.2 | 894 | max load; COL: 1.125"; 32,100 psi |
| Hodgdon Data Case: Hornady; twist: 1:16"; primer: Winchester SP, Small Pistol; barrel length: 4"; trim length: .845"; bullet diam.: .400". This data is intended for use in firearms with barrels which fully support the cartridge in the chamber. Use of this data in firearms which do not fully support the cartridge, such as Glock, may result in bulged cases, ruptured cases, case head separation, or other conditions which may result in damage to the firearm and/or result in injury or death of the shooter and/or bystanders. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 155 | Hornady HP-XTP | 6.1 | 1015 | |
| 155 | Hornady HP-XTP | 6.5 | 1071 | |
| 155 | Hornady HP-XTP | 6.9 | 1132 | |
| 155 | Hornady HP-XTP | 7.4 | 1199 | |
| 155 | Hornady HP-XTP | 7.8 | 1254 | maximum load |
| 180 | Hornady HAP or HP-XTP | 5.1 | 870 | |
| 180 | Hornady HAP or HP-XTP | 5.4 | 921 | |
| 180 | Hornady HAP or HP-XTP | 5.8 | 972 | |
| 180 | Hornady HAP or HP-XTP | 6.1 | 1021 | maximum load |
| 200 | Hornady HAP or HP-XTP | 3.9 | 706 | |
| 200 | Hornady HAP or HP-XTP | 4.3 | 755 | |
| 200 | Hornady HAP or HP-XTP | 4.6 | 805 | |
| 200 | Hornady HAP or HP-XTP | 5.0 | 852 | |
| 200 | Hornady HAP or HP-XTP | 5.3 | 899 | maximum load |
| Using Hornady Bullets Gun: Glock Model 22; barrel length: 4.35 inches; case: Starline; primer: Winchester Small Pistol; bullet diameter: .400"; COAL: 1.125"; maximum COAL: 1.135"; maximum case length: .850"; trim to length: .845". IMPORTANT: PLEASE VIEW THE SPECIAL NOTES by clicking here. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 135 | NOS | 8.0 | 1236 | starting load; 26,600 psi |
| 135 | NOS | 8.8 | 1342 | maximum load; 32,700 psi |
| 155 | HDY | 7.0 | 1109 | starting load; 25,800 psi |
| 155 | HDY | 7.8 | 1223 | maximum load; 33,800 psi |
| 165 | SIE | 6.5 | 1037 | starting load; 25,600 psi |
| 165 | SIE | 7.1 | 1124 | maximum load; 31,500 psi |
| 180 | HDY | 5.8 | 975 | starting load; 27,700 psi |
| 180 | HDY | 6.3 | 1053 | maximum load; 33,200 psi |
| 200 | HDY | 4.8 | 838 | starting load; 27,900 psi |
| 200 | HDY | 5.2 | 894 | maximum load; 32,100 psi |
| Winchester AutoComp Data | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 200 | Nosler Sporting Handgun Jacketed Hollow Point | 5.2 | 898 | maximum load |
| 200 | Nosler Sporting Handgun Jacketed Hollow Point | 4.7 | 829 | most accurate load tested |
| 200 | Nosler Sporting Handgun Jacketed Hollow Point | 4.2 | 760 | |
| Handgun Data (Using Nosler Bullets) Handgun; case: Winchester; primer: WSP; barrel length/make: 4" S&W; twist: 1-16"; bullets: 135 GR, 150 GR, 180 GR & 200 GR Nosler Sporting Handgun Pistol JHP; OACL: 1.125"; maximum OACL: 1.135". Use Maximum Loads with Caution | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 135 | Nosler JHP | 8.0 | 1336 | accuracy (inches): 1.43 |
| 135 | Nosler JHP | 8.4 | 1392 | accuracy (inches): 1.06 |
| 135 | Nosler JHP | 8.8 | 1437 | accuracy (inches): 1.09 |
| 155 | Speer Gold Dot | 7.0 | 1107 | accuracy (inches): 2.00 |
| 155 | Speer Gold Dot | 7.4 | 1139 | accuracy (inches): 1.98 |
| 155 | Speer Gold Dot | 7.8 | 1167 | accuracy (inches): 1.18 |
| 165 | Sierra JHP | 6.5 | 1101 | accuracy (inches): 2.85 |
| 165 | Sierra JHP | 6.8 | 1152 | accuracy (inches): 1.70 |
| 165 | Sierra JHP | 7.1 | 1184 | accuracy (inches): 1.52 |
| 180 | Sierra JHP | 5.8 | 1010 | accuracy (inches): 1.42 |
| 180 | Sierra JHP | 6.1 | 1042 | accuracy (inches): 1.47 |
| 180 | Sierra JHP | 6.3 | 1071 | accuracy (inches): 1.79 |
| Handloads Velocity data is the instrumental average of five rounds at 12 feet. Accuracy is a five-shot group at 25 yards from a Ransom Rest. Remington brass and CCI Small Pistol primers used throughout. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 155 | Speer Gold Dot HP | 6.0 | 997 | overall loaded length (inches): 1.120 |
| 155 | Speer Gold Dot HP | 6.5 | 1062 | overall loaded length (inches): 1.120 |
| 155 | Speer Gold Dot HP | 7.0 | 1128 | overall loaded length (inches): 1.120 |
| 155 | Speer Gold Dot HP | 7.5 | 1214 | overall loaded length (inches): 1.120 |
| 155 | Speer Gold Dot HP | 8.0 | 1269 | overall loaded length (inches): 1.120 |
| 180 | Nosler JHP | 5.0 | 865 | overall loaded length (inches): 1.125 |
| 180 | Nosler JHP | 5.5 | 933 | overall loaded length (inches): 1.125 |
| 180 | Nosler JHP | 6.0 | 997 | overall loaded length (inches): 1.125 |
| 180 | Nosler JHP | 6.2 | 1037 | overall loaded length (inches): 1.125 |
A Glock Model 22 with a 4.35-inch barrel was used to test-fire all loads. Starline cases and Winchester Small Pistol primers were used throughout. Bullet diameter: .400 inch; maximum cartridge overall length: 1.135 inches; maximum case length: .850 inch; trim-to length: .845 inch. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 210 | Hornady XTP | 9.1 | 1216 | start load; COL: 1.580"; 30,500 cup |
| 210 | Hornady XTP | 9.9 | 1303 | max load; COL: 1.580"; 38,200 cup |
| 215 | Cast LFP | 7.0 | 1052 | start load; COL: 1.585"; 18,100 cup |
| 215 | Cast LFP | 8.0 | 1158 | max load; COL: 1.585"; 23,600 cup |
| 220 | Speer JSP | 8.3 | 1154 | start load; COL: 1.580"; 32,500 cup |
| 220 | Speer JSP | 9.1 | 1221 | max load; COL: 1.580"; 38,300 cup |
| 245 | Cast LSWC | 8.3 | 1123 | start load; COL: 1.630"; 26,300 cup |
| 245 | Cast LSWC | 9.5 | 1232 | max load; COL: 1.630"; 36,200 cup |
| 250 | WFNGC | 7.5 | 1075 | start load; COL: 1.540"; 29,600 cup |
| 250 | WFNGC | 8.5 | 1163 | max load; COL: 1.540"; 37,600 cup |
| 255 | WFNGC | 7.7 | 1044 | start load; COL: 1.660"; 25,300 cup |
| 255 | WFNGC | 8.7 | 1141 | max load; COL: 1.660"; 36,000 cup |
| 265 | WLNGC | 7.7 | 1040 | start load; COL: 1.710"; 26,300 cup |
| 265 | WLNGC | 8.7 | 1132 | max load; COL: 1.710"; 35,700 cup |
| Hodgdon Pistol Data Case: Remington; twist: 1:18.75"; primer: Winchester LP; barrel length: 10.125"; trim length: 1.280"; BULLET DIAM.: .410". NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 180 | Barnes XPB FB | 10.5 | 1327 | |
| 180 | Barnes XPB FB | 11.0 | 1376 | |
| 180 | Barnes XPB FB | 11.5 | 1428 | |
| using Barnes X Pistol Bullets A 6 1/2-inch barreled Ruger Blackhawk was used to testfire the above loads. Starline cases and CCI 300 Large Pistol primers were used throughout. Bullet diameter: .410 inch; maximum cartridge length: 1.590 inches, tested at 1.580 inches; maximum case length: 1.290 inches; trim-to length: 1.280 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 165 | LRNFP Cast | 8.0 | 1072 | start load; COL: 1.500"; 13,100 psi |
| 165 | LRNFP Cast | 9.0 | 1185 | max load; COL: 1.500"; 15,300 psi |
| 180 | Hornady XTP | 12.6 | 1419 | start load; COL: 1.600"; 26,800 psi |
| 180 | Hornady XTP | 13.8 | 1527 | max load; COL: 1.600"; 31,700 psi |
| 200 | LRNFP Cast | 7.0 | 939 | start load; COL: 1.570"; 13,200 psi |
| 200 | LRNFP Cast | 8.0 | 1038 | max load; COL: 1.570"; 15,400 psi |
| 200 | Nosler JHP | 12.0 | 1348 | start load; bullet diam.: .429"; COL: 1.600"; 27,000 psi |
| 200 | Nosler JHP | 13.2 | 1429 | max load; bullet diam.: .429"; COL: 1.600"; 32,500 psi |
| 210 | Sierra JHC | 11.5 | 1341 | start load; COL: 1.600"; 27,700 psi |
| 210 | Sierra JHC | 12.5 | 1414 | max load; COL: 1.600"; 34,600 psi |
| 220 | Berrys Bullets FP | 8.3 | 878 | start load; COL: 1.610"; 12,700 psi |
| 220 | Berrys Bullets FP | 10.6 | 1127 | max load; COL: 1.610"; 19,900 psi |
| 225 | Speer JHP | 10.8 | 1266 | start load; COL: 1.575"; 28,300 psi |
| 225 | Speer JHP | 11.8 | 1352 | max load; COL: 1.575"; 34,200 psi |
| 240 | LSWC Cast | 7.0 | 886 | start load; COL: 1.620"; 13,800 psi |
| 240 | LSWC Cast | 8.0 | 996 | max load; COL: 1.620"; 16,200 psi |
| 240 | Nosler JHP | 10.0 | 1129 | start load; bullet diam.: .429"; COL: 1.600"; 26,000 psi |
| 240 | Nosler JHP | 11.5 | 1250 | max load; bullet diam.: .429"; COL: 1.600"; 34,100 psi |
| 240 | Speer GDSP | 9.7 | 1106 | start load; bullet diam.: .429"; COL: 1.600"; 28,000 psi |
| 240 | Speer GDSP | 10.8 | 1199 | max load; bullet diam.: .429"; COL: 1.600"; 34,600 psi |
| 280 | Swift JHP | 9.0 | 1005 | start load; COL: 1.700"; 26,600 psi |
| 280 | Swift JHP | 10.2 | 1115 | max load; COL: 1.700"; 32,500 psi |
| 300 | Hornady XTP | 8.0 | 866 | start load; COL: 1.600"; 26,300 psi |
| 300 | Hornady XTP | 9.0 | 927 | max load; COL: 1.600"; 33,500 psi |
| 325 | Beartooth Bullets LFN GC | 9.0 | 1008 | start load; COL: 1.730"; 26,100 psi |
| 325 | Beartooth Bullets LFN GC | 10.0 | 1075 | max load; COL: 1.730"; 30,900 psi |
| 330 | Beartooth Bullets LFN GC | 8.8 | 976 | start load; COL: 1.730"; 25,200 psi |
| 330 | Beartooth Bullets LFN GC | 9.8 | 1056 | max load; COL: 1.730"; 30,900 psi |
| 355 | Beartooth Bullets LFN GC | 7.8 | 906 | start load; COL: 1.710"; 25,600 psi |
| 355 | Beartooth Bullets LFN GC | 8.5 | 959 | max load; COL: 1.710"; 29,900 psi |
| Hodgdon Pistol Data - Winchester Powder Case: Winchester; barrel length: 8.275"; twist: 1:20"; trim length: 1.280"; primer: Remington 2 1/2; bullet diam.: .430" (except where otherwise specified in remarks). NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 240 | Nosler JHP | 10.0 | 994 | overall loaded length (inches): 1.585 |
| 240 | Nosler JHP | 11.0 | 1058 | overall loaded length (inches): 1.585 |
| 240 | Nosler JHP | 12.0 | 1110 | overall loaded length (inches): 1.585 |
| 240 | Sierra | 11.0 | 1065 | overall loaded length (inches): 1.595 |
| 240 | Sierra | 12.0 | 1118 | overall loaded length (inches): 1.595 |
| Handloading Data A Smith & Wesson Model 69 with a 4 1/4-inch barrel was used to test fire these loads. Starline cases were used throughout. Maximum case length: 1.285 inches; trim-to length: 1.275 inches; primer: CCI 300 (except where otherwise specified in remarks). | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 165 | Cast LRNFP | 7.4 | 1028 | start load; COL: 1.365"; 8,800 cup |
| 165 | Cast LRNFP | 8.0 | 1112 | max load; COL: 1.365"; 13,400 cup |
| 200 | Cast LRNFP | 6.4 | 880 | start load; COL: 1.450"; 9,900 cup |
| 200 | Cast LRNFP | 6.9 | 944 | max load; COL: 1.450"; 12,000 cup |
| 200 | Nosler JHP | 6.5 | 849 | start load; COL: 1.460"; bullet diam.: .429"; 9,500 cup |
| 200 | Nosler JHP | 7.1 | 937 | max load; COL: 1.460"; bullet diam.: .429"; 12,300 cup |
| 220 | Berry's Bullets FP | 6.4 | 828 | start load; COL: 1.460"; 8,900 cup |
| 220 | Berry's Bullets FP | 7.3 | 937 | max load; COL: 1.460"; 13,300 cup |
| 240 | Cast LSWC | 5.5 | 769 | start load; COL: 1.450"; 8,400 cup |
| 240 | Cast LSWC | 6.5 | 903 | max load; COL: 1.450"; 13,400 cup |
| Hodgdon Data Case: Starline; barrel length: 8"; twist: 1:20"; trim length: 1.155"; primer: Winchester LP; bullet diam. .430" (except where otherwise specified in remarks). NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 155 | Cast LSWC | 7.6 | 1006 | start load; COL: 1.230"; 13,700 cup |
| 155 | Cast LSWC | 8.2 | 1079 | max load; COL: 1.230"; 16,600 cup |
| 155 | SinterFire | 6.2 | 875 | start load; COL: 1.220"; 15,000 psi |
| 155 | SinterFire | 7.0 | 1000 | max load; COL: 1.220"; 18,600 psi |
| 160 | Barnes TAC-XP | 6.7 | 1036 | start load; COL: 1.200"; 18,400 psi |
| 160 | Barnes TAC-XP | 7.2 | 1105 | max load; COL: 1.200"; 20,100 psi |
| 180 | LFP | 6.8 | 903 | start load; bullet diam.: .452"; COL: 1.140"; 12,800 cup |
| 180 | LFP | 7.6 | 1008 | max load; bullet diam.: .452"; COL: 1.140"; 16,500 cup |
| 185 | Hornady JSWC | 6.7 | 856 | start load; COL: 1.135"; 12,600 cup |
| 185 | Hornady JSWC | 7.4 | 958 | max load COL: 1.135"; 16,200 cup |
| 200 | Speer JHP | 6.4 | 856 | start load; COL: 1.155"; 12,600 cup |
| 200 | Speer JHP | 7.0 | 930 | max load; COL: 1.155"; 16,000 cup |
| 200 | Cast LSWC | 6.5 | 843 | start load; COL: 1.225"; 11,500 cup |
| 200 | Cast LSWC | 7.2 | 914 | max load; COL: 1.225"; 15,100 cup |
| 230 | LRN | 6.1 | 832 | start load; bullet diam.: .452"; COL: 1.200"; 13,700 cup |
| 230 | LRN | 6.6 | 896 | max load; bullet diam.: .452"; COL: 1.200"; 16,400 cup |
| 230 | Hornady FMJ FP | 6.0 | 789 | start load; COL: 1.200"; 13,800 cup |
| 230 | Hornady FMJ FP | 6.6 | 871 | max load; COL: 1.200"; 17,100 cup |
| Hodgdon Data Case: Winchester; twist: 1:16"; primer: Federal 150, Large Pistol; barrel length: 5"; trim length: .893"; bullet diam.: .451" (except where otherwise specified in remarks) | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 230 | Rocky Mountain Reloading FMJ-RN | 6.0 | 785 | |
| 230 | Rocky Mountain Reloading FMJ-RN | 6.4 | 833 | |
| 230 | Rocky Mountain Reloading FMJ-RN | 6.8 | 866 | |
| in a Ruger SR1911 Warning! Gun: Ruger SR1911; Barrel Length: 5 inches; Case: Starline; Primer: CCI 300; Bullet Diameter: .451 and .452 inch; Maximum Case Length: .898 inch; Trim-to Length: .893 inch; COAL for X-Treme Plated SWC: 1.240 inches; COAL for Rocky Mtn. Reloading FMJ-RN: 1.210 inches; Source: Handloader issue 300 / February-March 2016 | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 185 | HDY | 6.7 | 856 | starting load; 12,600 cup |
| 185 | HDY | 7.4 | 958 | maximum load; 16,200 cup |
| 200 | LSWEC | 6.5 | 843 | starting load; 11,500 cup |
| 200 | LSWEC | 7.2 | 914 | maximum load; 15,100 cup |
| 200 | SPR | 6.4 | 856 | starting load; 12,600 cup |
| 200 | SPR | 7.0 | 930 | maximum load; 16,000 cup |
| 230 | HDY | 6.0 | 789 | starting load; 13,800 cup |
| 230 | HDY | 6.6 | 871 | maximum load; 17,100 cup |
| 230 | LRN | 6.1 | 832 | starting load; 13,700 cup |
| 230 | LRN | 6.6 | 896 | maximum load; 16,400 cup |
| Winchester AutoComp Data | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 225 | Hornady FTX | 7.1 | 750 | start load; COL: 1.600"; 8,700 psi |
| 225 | Hornady FTX | 8.9 | 973 | max load; COl: 1.600"; 13,600 psi |
| 250 | Cast LRNFP | 7.8 | 867 | start load; COL: 1.600"; 12,600 psi |
| 250 | Cast LRNFP | 8.5 | 923 | max load; COL: 1.600"; 13,200 psi |
| 250 | Hornady XTP | 7.7 | 757 | start load; COL: 1.595"; 12,200 psi |
| 250 | Hornady XTP | 8.4 | 839 | max load; COL: 1.595"; 13,500 psi |
| 260 | Speer JHP | 7.4 | 728 | start load; COL: 1.595"; 11,800 psi |
| 260 | Speer JHP | 8.0 | 770 | max load; COL: 1.595"; 13,500 psi |
| Hodgdon Pistol Data Case: Winchester; barrel length: 7.25"; twist: 1:16"; trim length: 1.280"; primer: Winchester LP; bullet diam.: .452". NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 250 | Oregon Trail RNFP | 9.0 | 1213 | overall loaded length (inches): 1.575 |
| 250 | Oregon Trail RNFP | 9.5 | 1244 | overall loaded length (inches): 1.575 |
| higher pressure loads Warning! A Browning Model 1885 Traditional Hunter with a 24-inch barrel was used to test-fire these loads. Starline cases and CCI 300 primers were used throughout. Bullet diameter: .452 inch; maximum case length: 1.285 inches; case trim-to length: 1.275 inches. Source: Rifle Single Shot Special Edition 2015. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 255 | X-Treme Plated FP | 7.8 | 716 | DO NOT REDUCE |
| 255 | X-Treme Plated FP | 8.2 | 771 | |
| 255 | X-Treme Plated FP | 8.5 | 813 | |
| in a Ruger New Model Blackhawk Bisley Warning! Gun: Ruger New Model Blackhawk Bisley; Barrel Length: 5 1/2 inches; Cases: Starline; Primer: CCI 300; Bullet Diameter: .452 inch; Maximum Case Length: 1.285 inches; Trim-to Length: 1.275 inches; COAL: 1.570 inches; Source: Handloader issue 300 / February-March 2016 | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 250 | Oregon Trail Laser-Cast RNFP | 9.0 | 860 | |
| Traditional Handload Data All loads, fired from a 4 3/4-inch barreled USFA Pre-War SAA, produced between 850 and 870 fps average velocity and are thus listed at 860 fps to more or less duplicate traditional .45 Colt ballistics. Starline cases and CCI 300 Large Pistol primers were used throughout. Overall loaded length: 1.575 inches. Bullet diameter: .452 inch used herein (.454 inch suggested for guns with throats .454 or larger); maximum case length: 1.285 inches; trim-to case length: 1.275 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 155 | Cast LSWC | 6.9 | 937 | starting load; psi: 17,500 |
| 155 | Cast LSWC | 7.5 | 1089 | maximum load; psi: 21,200 |
| 185 | Hornady XTP | 6.7 | 809 | starting load; psi: 18,100 |
| 185 | Hornady XTP | 7.3 | 911 | maximum load; psi: 21,400 |
| 200 | Speer GDHP | 6.3 | 727 | starting load; psi: 17,400 |
| 200 | Speer GDHP | 6.9 | 814 | maximum load; psi: 21,100 |
| Hodgdon Pistol Data Never exceed the loads listed here. case: Speer; BBL: 5 inches; PR: Winchester SP; twist: 1:16 inches; trim: .750 inch | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 135 | Nosler JHP | 8.7 | 1372 | starting load; 28,400 psi; COL: 1.250" |
| 135 | Nosler JHP | 9.5 | 1476 | maximum load; 34,500 psi; COL: 1.250" |
| 155 | Hornady XTP | 8.0 | 1254 | starting load; 29,000 psi |
| 155 | Hornady XTP | 8.9 | 1362 | maximum load; 35,700 psi |
| 180 | Sierra JHC | 7.0 | 1119 | starting load; 29,800 psi |
| 180 | Sierra JHC | 7.7 | 1199 | maximum load; 36,000 psi |
| 200 | Hornady FMJ | 6.0 | 959 | starting load; 25,900 psi |
| 200 | Hornady FMJ | 7.0 | 1100 | maximum load; 36,100 psi |
| Winchester Data case: Winchester; barrel length: 5"; twist: 1:16"; trim length: .987"; primer: Winchester LP; bullet diam.: .400"; COL: 1.260" (except where otherwise specified in remarks); NEVER EXCEED MAXIMUM LOADS | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 124 | Rocky Mountain Reloading TC | 4.0 | 950 | |
| 124 | Rocky Mountain Reloading TC | 4.5 | 1051 | |
| 124 | Rocky Mountain Reloading TC | 5.0 | 1170 | |
| in a Kimber Model 1911 Team Match II Warning! Gun: Kimber Model 1911 Team Match II; Barrel Length: 5 inches; Cases: Starline; Primer: CCI 500; Bullet Diameter: .355 inch; Maximum Case Length: .754 inch; Trim-to Length: .749 inch; COAL: 1.050 inches; Source: Handloader issue 300 / Feb-March 2016 | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 147 | Hornady HPBT-XTP | 3.5 | 838 | overall loaded length (inches): 1.100 |
| 147 | Hornady HPBT-XTP | 4.1 | 959 | overall loaded length (inches): 1.100 |
| 147 | Speer TMJ-FN | 3.5 | 842 | overall loaded length (inches): 1.130 |
| 147 | Speer TMJ-FN | 4.0 | 939 | overall loaded length (inches): 1.130 |
| 147 | Speer TMJ-FN | 4.3 | 1014 | overall loaded length (inches): 1.130 |
| (147 GR) Handload Data A 5-inch barreled Kimber Model 1911 Team Match II was used to shoot all loads in Starline cases with Winchester Small Pistol primers. SAAMI minimum cartridge overall length: 1.000 inch; maximum cartridge overall length: 1.169 inches; maximum case length: .754 inch; trim to length: .744 inch. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 90 | Hornady HP-XTP | 5.7 | 1233 | overall loaded length (inches): 1.070 |
| 90 | Hornady HP-XTP | 6.6 | 1450 | overall loaded length (inches): 1.070 |
| 90 | Hornady HP-XTP | 6.8 | 1498 | overall loaded length (inches): 1.070 |
| 90 | Sierra JHP | 5.5 | 1218 | overall loaded length (inches): 1.010 |
| 90 | Sierra JHP | 5.9 | 1329 | overall loaded length (inches): 1.010 |
| 90 | Sierra JHP | 6.2 | 1402 | overall loaded length (inches): 1.010 |
| 115 | Barnes XPB | 5.1 | 1218 | overall loaded length (inches): 1.125 |
| 115 | Barnes XPB | 5.5 | 1274 | overall loaded length (inches): 1.125 |
| 115 | Barnes XPB | 5.8 | 1341 | overall loaded length (inches): 1.125 |
| 115 | Hornady HP-XTP | 4.7 | 1068 | overall loaded length (inches): 1.075 |
| 115 | Hornady HP-XTP | 5.5 | 1252 | overall loaded length (inches): 1.075 |
| 115 | Hornady HP-XTP | 5.8 | 1295 | overall loaded length (inches): 1.075 |
| (90 & 115 GR) Handload Data A 5-inch barreled Kimber Model 1911 Team Match II was used to shoot all loads in Starline cases with Winchester Small Pistol primers. SAAMI minimum cartridge overall length: 1.000 inch; maximum cartridge overall length: 1.169 inches; maximum case length: .754 inch; trim to length: .744 inch. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 80 | Barnes TAC-XP | 4.4 | 1101 | start load; COL: 1.025"; 27,700 psi |
| 80 | Barnes TAC-XP | 4.8 | 1207 | max load; COL: 1.025"; 31,800 psi |
| 90 | Speer GDHP | 6.1 | 1255 | start load; COL: 1.010"; 27,700 psi |
| 90 | Speer GDHP | 6.5 | 1332 | max load; COL: 1.010"; 32,100 psi |
| 95 | Sierra FMJ | 5.6 | 1216 | start load; COL: 1.020"; 27,300 psi |
| 95 | Sierra FMJ | 6.1 | 1306 | max load; COL: 1.020"; 32,600 psi |
| 115 | Speer GDHP | 5.1 | 1078 | start load; COL: 1.125"; 28,200 psi |
| 115 | Speer GDHP | 5.6 | 1161 | max load; COL: 1.125"; 32,500 psi |
| 115 | Lead Round Nose | 4.4 | 1002 | start load; bullet diam.: .356"; COL: 1.100"; 24,800 psi |
| 115 | Lead Round Nose | 5.1 | 1145 | max load; bullet diam.: .356"; COL: 1.100"; 31,500 psi |
| 124 | Berry's Bullets HBRN TP | 4.8 | 1020 | start load; bullet diam.: .356"; COL: 1.150"; 28,400 psi |
| 124 | Berry's Bullets HBRN TP | 5.4 | 1120 | max load; bullet diam.: .356"; COL: 1.150"; 32,900 psi |
| 125 | Lead Conical Nose | 4.3 | 1012 | start load; bullet diam.: .356"; COL: 1.125"; 26,700 psi |
| 125 | Lead Conical Nose | 4.8 | 1101 | max load; bullet diam.: .356"; COL: 1.125"; 32,800 psi |
| 125 | Sierra FMJ | 4.7 | 1055 | start load; COL: 1.090"; 28,900 psi |
| 125 | Sierra FMJ | 5.2 | 1120 | max load; COL: 1.090"; 33,300 psi |
| 125 | Hornady HAP | 3.6 | 842 | start load; bullet diam.: .356"; COL: 1.069"; 25,000 psi |
| 125 | Hornady HAP | 4.1 | 954 | max load; bullet diam.: .356"; COL: 1.069"; 31,600 psi |
| 130 | Berry's Bullets RN | 4.8 | 990 | start load; bullet diam.: .356"; COL: 1.150"; 27,500 psi |
| 130 | Berry's Bullets RN | 5.3 | 1093 | max load; bullet diam.: .356"; COL: 1.150"; 33,500 psi |
| 147 | Hornady XTP | 3.6 | 827 | start load; COL: 1.100"; 27,900 psi |
| 147 | Hornady XTP | 4.0 | 916 | max load; COL: 1.100"; 32,800 psi |
| Hodgdon Data Using Winchester Powder Case: Winchester; twist: 1:10"; primer: CCI 500, Small Pistol; barrel length: 4"; trim length: .750"; bullet diam.: .355" (except where otherwise specified in remarks). | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 115 | Hornady HP-XTP or FMJ-RN | 4.7 | 1068 | |
| 115 | Hornady HP-XTP or FMJ-RN | 5.0 | 1129 | |
| 115 | Hornady HP-XTP or FMJ-RN | 5.2 | 1190 | |
| 115 | Hornady HP-XTP or FMJ-RN | 5.5 | 1252 | maximum load |
| (Using 115 GR Hornady Bullets) Gun: Kimber 1911; barrel length: 5-inch; case: Starline; primer: Winchester Small Pistol; bullet diameter: .355"; HP-XTP COAL: 1.075"; FMJ-RN COAL: 1.100"; maximum COAL: 1.169"; maximum case length: .754"; trim to length: .749". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 124 | Hornady HP-XTP | 4.2 | 964 | |
| 124 | Hornady HP-XTP | 4.4 | 1017 | |
| 124 | Hornady HP-XTP | 4.7 | 1070 | |
| 124 | Hornady HP-XTP | 4.9 | 1122 | maximum load |
| (Using 124 GR Hornady Bullets) Gun: Kimber 1911; barrel length: 5-inch; case: Starline; primer: Winchester Small Pistol; bullet diameter: .355"; COAL: 1.060"; maximum COAL: 1.169"; maximum case length: .754"; trim to length: .749". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 147 | Hornady HP-BT-XTP | 3.5 | 838 | |
| 147 | Hornady HP-BT-XTP | 3.7 | 878 | |
| 147 | Hornady HP-BT-XTP | 4.0 | 918 | |
| 147 | Hornady HP-BT-XTP | 4.1 | 959 | maximum load |
| (Using 147 GR Hornady Bullets) Gun: Kimber 1911; barrel length: 5-inch; case: Starline; primer: Winchester Small Pistol; bullet diameter: .355"; COAL: 1.100"; maximum COAL: 1.169"; maximum case length: .754"; trim to length: .749". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 90 | Hornady HP-XTP | 5.7 | 1233 | |
| 90 | Hornady HP-XTP | 6.0 | 1279 | |
| 90 | Hornady HP-XTP | 6.2 | 1336 | |
| 90 | Hornady HP-XTP | 6.4 | 1392 | |
| 90 | Hornady HP-XTP | 6.6 | 1450 | |
| 90 | Hornady HP-XTP | 6.8 | 1498 | maximum load |
| (Using 90 GR Hornady Bullets) Gun: Kimber 1911; barrel length: 5-inch; case: Starline; primer: Winchester Small Pistol; bullet diameter: .355"; COAL: 1.070"; maximum COAL: 1.169"; maximum case length: .754"; trim to length: .749". | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 115 | Nosler Sporting Handgun Pistol JHP | 5.5 | 1139 | max; most accurate load tested |
| 115 | Nosler Sporting Handgun Pistol JHP | 5.0 | 1055 | |
| 115 | Nosler Sporting Handgun Pistol JHP | 4.5 | 979 | |
| 124 | Nosler Sporting Handgun Pistol JHP | 5.1 | 1144 | max; most accurate load tested |
| 124 | Nosler Sporting Handgun Pistol JHP | 4.6 | 1061 | |
| 124 | Nosler Sporting Handgun Pistol JHP | 4.1 | 978 | |
| Using Nosler Bullets Case: Winchester; primer: Rem 1 1/2; barrel length/make: 4" Douglas; twist: 1-16"; bullets: 115 GR Nosler Sporting Handgun Pistol JHP - OACL: 1.100"; 124 GR Nosler Sporting Handgun Pistol JHP - OACL: 1.120"; maximum OACL: 1.169". Use Maximum Loads with Caution | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 115 | LRN | 4.4 | 1002 | starting load; 24,800 psi |
| 115 | LRN | 5.1 | 1145 | maximum load; 31,500 psi |
| 115 | SPR | 5.1 | 1078 | starting load; 28,200 psi |
| 115 | SPR | 5.6 | 1161 | maximum load; 32,500 psi |
| 125 | LCN | 4.3 | 1012 | starting load; 26,700 psi |
| 125 | LCN | 4.8 | 1101 | maximum load; 32,800 psi |
| 125 | SIE | 4.7 | 1055 | starting load; 28,900 psi |
| 125 | SIE | 5.2 | 1120 | maximum load; 33,300 psi |
| 130 | SIE | 4.4 | 933 | starting load; 24,900 psi |
| 130 | SIE | 5.0 | 1055 | maximum load; 31,800 psi |
| 147 | HDY | 3.6 | 827 | starting load; 27,900 psi |
| 147 | HDY | 4.0 | 916 | maximum load; 32,800 psi |
| Winchester AutoComp Data | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 124 | Hornady HP-XTP | 4.2 | 964 | overall loaded length (inches): 1.060 |
| 124 | Hornady HP-XTP | 4.4 | 1017 | overall loaded length (inches): 1.060 |
| 124 | Hornady HP-XTP | 4.7 | 1070 | overall loaded length (inches): 1.060 |
| 124 | Hornady HP-XTP | 4.9 | 1122 | overall loaded length (inches): 1.060 |
| 124 | Speer Gold Dot HP | 4.0 | 933 | overall loaded length (inches): 1.120 |
| 124 | Speer Gold Dot HP | 4.5 | 1015 | overall loaded length (inches): 1.120 |
| 124 | Speer Gold Dot HP | 5.0 | 1142 | overall loaded length (inches): 1.120 |
| 124 | Oregon Trail cast RN | 3.8 | 981 | overall loaded length (inches): 1.045 |
| 124 | Oregon Trail cast RN | 4.5 | 1116 | overall loaded length (inches): 1.045 |
| 125 | Sierra FMJ | 4.5 | 1037 | overall loaded length (inches): 1.135 |
| 125 | Sierra FMJ | 5.0 | 1147 | overall loaded length (inches): 1.135 |
| Handload Data A 5-inch barreled Kimber Model 1911 Team Match II was used to shoot all loads in Starline cases with Winchester Small Pistol primers. SAAMI minimum cartridge overall length: 1.000 inch; maximum cartridge overall length: 1.169 inches; maximum case length: .754 inch; trim to length: .744 inch. | |||||
