Smokeless spherical magnum pistol powder
Utilize our premium performance, consistent quality new powder offerings the next time you pull the trigger. - Improved velocity and density for more efficient metering and loading
- Maximum velocity and performance in magnum handguns
- Enables reloaders to duplicate certain factory loaded ammunition
- Density designed for proper cartridge fit
Principal Purpose: Magnum Handgun/Pistol
Secondary Uses: .22 Hornet
| Shape | Color | Perforation | Diameter min | Diameter max | Length/thick. min | Length/thick. max | Manufacturer |
|---|---|---|---|---|---|---|---|
Ladedata som finnes på hjemmesidene til Evje PK er KUN ment som en veiledning! Ladedata skal alltid verifiseres mot kjente kilder (kruttprodusenter, ladebøker o.l.)
Data funnet på våre hjemmesider brukes på eget ansvar, og Evje Pistolklubb fratar seg alt ansvar for feil bruk av, eller skrivefeil i oppgitte data.
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
 | 90 | Sierra JHC | 13.0 | 1451 | |
| 90 | Sierra JHC | 14.0 | 1498 | |
| 90 | Sierra JHC | 15.0 | 1554 | |
| 100 | Speer JHP | 12.5 | 1331 | |
| 100 | Speer JHP | 13.5 | 1400 | |
| 100 | Speer JHP | 14.5 | 1460 | |
| 115 | Speer Gold Dot | 12.5 | 1301 | |
| 115 | Speer Gold Dot | 13.5 | 1402 | |
| 115 | Speer Gold Dot | 14.0 | 1436 | |
primer: CCI 550; case: Federal. Loads were fired in a USFA Sparrow Hawk with a 7 1/2-inch barrel. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 90 | Sierra JHC | 13.0 | 1187 | overall loaded length (inches): 1.467 |
| 90 | Sierra JHC | 13.5 | 1231 | overall loaded length (inches): 1.467 |
| 90 | Sierra JHC | 14.0 | 1283 | overall loaded length (inches): 1.467 |
| 90 | Sierra JHC | 14.5 | 1335 | overall loaded length (inches): 1.467 |
| 90 | Sierra JHC | 15.0 | 1378 | overall loaded length (inches): 1.467 |
| 100 | Hornady XTP | 12.5 | 1166 | overall loaded length (inches): 1.455 |
| 100 | Hornady XTP | 13.0 | 1208 | overall loaded length (inches): 1.455 |
| 100 | Hornady XTP | 13.5 | 1260 | overall loaded length (inches): 1.455 |
| 100 | Hornady XTP | 14.0 | 1312 | overall loaded length (inches): 1.455 |
| 100 | Hornady XTP | 14.5 | 1355 | overall loaded length (inches): 1.455 |
| 115 | Speer GDHP | 12.5 | 1180 | overall loaded length (inches): 1.450 |
| 115 | Speer GDHP | 13.0 | 1211 | overall loaded length (inches): 1.450 |
| 115 | Speer GDHP | 13.5 | 1252 | overall loaded length (inches): 1.450 |
| 115 | Speer GDHP | 14.0 | 1282 | overall loaded length (inches): 1.450 |
| Handloads A Ruger Single-Seven with a 7 1/2-inch barrel was used to test fire these loads. Federal cases and CCI 500 primers were used throughout. Bullet diameter: .312 and .313 inch; maximum case length: 1.200 inches; trim to length: 1.195 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 125 | Speer GDHP | 22.3 | 2000 | OAL: 1.580"; compressed load |
| 158 | Speer UCSP | 18.6 | 1690 | OAL: 1.570" |
| 170 | Speer GDSP | 17.5 | 1620 | OAL: 1.590" |
| Alliant Power Pro Data - 2010 Primer: Fed 100; case: Federal. NOTE: All loads are maximum. Reduce by 10% to establish a starting charge weight. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 125 | Speer JHP | 20.0 | 1360 | |
| 125 | Speer JHP | 21.0 | 1451 | |
| 125 | Speer JHP | 22.3 | 1569 | |
| 140 | Hornady HP-XTP | 18.5 | 1371 | |
| 140 | Hornady HP-XTP | 19.5 | 1455 | |
| 140 | Hornady HP-XTP | 20.5 | 1549 | |
| 158 | Sierra JSP | 17.0 | 1253 | |
| 158 | Sierra JSP | 18.0 | 1335 | |
| 158 | Sierra JSP | 18.5 | 1405 | |
| 160 | Lyman 358156 HP | 16.5 | 1420 | |
| 160 | Lyman 358156 HP | 17.5 | 1475 | |
| 160 | Lyman 358156 HP | 18.5 | 1556 | |
primer: Federal 100; case: Starline. A 6-inch barreled Ruger GP100 was used to fire the .357 Magnum loads. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 125 | Speer Gold Dot hollowpoint | 21.0 | 1316 | primer: CCI 500; overall loaded length (inches): 1.578 |
| 125 | Speer Gold Dot hollowpoint | 22.0 | 1405 | primer: CCI 500; overall loaded length (inches): 1.578 |
| 125 | Speer Gold Dot hollowpoint | 22.5 | 1441 | primer: CCI 500; overall loaded length (inches): 1.578 |
| 158 | Hornady HP-XTP | 17.0 | 1149 | primer: CCI 500; overall loaded length (inches): 1.580 |
| 158 | Hornady HP-XTP | 18.0 | 1239 | primer: CCI 500; overall loaded length (inches): 1.580 |
| 158 | Hornady HP-XTP | 19.0 | 1309 | primer: CCI 500; overall loaded length (inches): 1.580 |
| in a Smith & Wesson Model 627-5 Starline cases were used throughout. Maximum case length: 1.290 inches; trim-to length: 1.280 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 175 | Winchester Silvertip HP | 22.0 | 1227 | |
| 175 | Winchester Silvertip HP | 23.0 | 1298 | |
| 175 | Winchester Silvertip HP | 24.0 | 1353 | |
| 210 | Speer Gold Dot HP | 21.0 | 1275 | |
| 210 | Speer Gold Dot HP | 22.0 | 1320 | |
| 210 | Speer Gold Dot HP | 23.0 | 1380 | |
| 226 | Mt. Baldy Keith cast | 21.0 | 1347 | |
| 226 | Mt. Baldy Keith cast | 22.0 | 1379 | |
| 226 | Mt. Baldy Keith cast | 23.0 | 1440 | |
| 265 | O.T. TrueShot WNFP | 18.0 | 1152 | |
| 265 | O.T. TrueShot WNFP | 19.0 | 1229 | |
| 265 | O.T. TrueShot WNFP | 20.0 | 1277 | |
primer: CCI 300; case: Starline. Loads were fired from a Ruger Bisley with a 5 1/2-inch barrel. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 210 | Nosler JHP | 22.0 | 1394 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 210 | Nosler JHP | 23.0 | 1436 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 210 | Sierra JHC | 22.0 | 1380 | primer: CCI 300; overall loaded length (inches): 1.568 |
| 210 | Sierra JHC | 23.0 | 1413 | primer: CCI 300; overall loaded length (inches): 1.568 |
| 210 | Speer Deepcurl HP | 22.0 | 1349 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 210 | Speer Deepcurl HP | 23.0 | 1418 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 226 | Redding 410 cast | 21.0 | 1352 | primer: CCI 300; overall loaded length (inches): 1.674; Brinell hardness number 17 |
| 226 | Redding 410 cast | 22.0 | 1409 | primer: CCI 300; overall loaded length (inches): 1.674; Brinell hardness number 17 |
| 226 | Redding 410 cast | 23.0 | 1467 | primer: CCI 300; overall loaded length (inches): 1.674; Brinell hardness number 17 |
| 265 | Oregon Trail TrueShot FP | 18.0 | 1175 | primer: CCI 300 |
| 265 | Oregon Trail TrueShot FP | 19.0 | 1260 | primer: CCI 300 |
| 265 | Oregon Trail TrueShot FP | 20.0 | 1293 | primer: CCI 300 |
| in a Ruger Blackhawk, 6 1/2-inch barrel Ruger Blackhawk, 6 1/2-inch barrel. Starline brass used for all loads. SAAMI maximum overall loaded length is 1.590 inches. Maximum case length: 1.290 inches; trim-to length: 1.280 inches. Bullets cast from Lyman mould 410459 will vary in weight from 216 to 221 grains, depending on the individual mould, alloy and or lubricant used. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 175 | Winchester Silvertip HP | 22.0 | 1227 | primer: CCI 300 |
| 175 | Winchester Silvertip HP | 23.0 | 1298 | primer: CCI 300 |
| 175 | Winchester Silvertip HP | 24.0 | 1353 | primer: CCI 300 |
| 210 | Speer Deepcurl HP | 21.0 | 1275 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 210 | Speer Deepcurl HP | 22.0 | 1320 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 210 | Speer Deepcurl HP | 23.0 | 1380 | primer: CCI 300; overall loaded length (inches): 1.570 |
| 226 | Mt. Baldy Keith cast (discontinued) | 21.0 | 1347 | primer: CCI 300; overall loaded length (inches): 1.700 |
| 226 | Mt. Baldy Keith cast (discontinued) | 22.0 | 1379 | primer: CCI 300; overall loaded length (inches): 1.700 |
| 226 | Mt. Baldy Keith cast (discontinued) | 23.0 | 1440 | primer: CCI 300; overall loaded length (inches): 1.700 |
| 265 | Oregon Trail TrueShot WNFP GC | 18.0 | 1152 | primer: CCI 300; overall loaded length (inches): 1.710 |
| 265 | Oregon Trail TrueShot WNFP GC | 19.0 | 1229 | primer: CCI 300; overall loaded length (inches): 1.710 |
| 265 | Oregon Trail TrueShot WNFP GC | 20.0 | 1277 | primer: CCI 300; overall loaded length (inches): 1.710 |
| in a Ruger New Model Blackhawk Bisley Ruger New Model Blackhawk Bisley (stainless), 5 1/2-inch barrel. Starline brass used for all loads. SAAMI maximum overall loaded length is 1.590 inches. Maximum case length: 1.290 inches; trim-to length: 1.280 inches. Bullets cast from Lyman mould 410459 will vary in weight from 216 to 221 grains, depending on the individual mould, alloy and or lubricant used. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 265 | TrueShot WNFP-GC | 18.0 | 1170 | primer: CCI 300 |
| 265 | TrueShot WNFP-GC | 19.0 | 1213 | primer: CCI 300 |
| 265 | TrueShot WNFP-GC | 20.0 | 1277 | primer: CCI 300 |
| Oregon Trail Cast Bullet Loads Ruger Blackhawk; 6 1/2-inch barrel; case: Starline; overall loaded length (inches): 1.715; maximum case length: 1.290 inches; trim-to length: 1.280 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 220 | 20.0 | 1202 | ||
Magnum strength primers used exclusively. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 200 | Speer Mag HP | 29.0 | 1760 | OAL: 1.590" |
| 240 | Speer GDSP | 25.0 | 1570 | OAL: 1.575" |
| 270 | Speer GDSP | 22.0 | 1400 | OAL: 1.585" |
| 300 | Speer UCSP | 22.0 | 1350 | OAL: 1.665" |
| Alliant Power Pro Data 2010 Primer: Fed 150; case: Federal; NOTE: All loads are maximum. Reduce by 10% to establish a starting charge weight. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 310 | TrueShot WNFP-GC | 20.0 | 1254 | primer: CCI 300 |
| 310 | TrueShot WNFP-GC | 21.0 | 1304 | primer: CCI 300 |
| 310 | TrueShot WNFP-GC | 22.0 | 1367 | primer: CCI 300 |
| Oregon Trail Cast Bullet Loads Ruger New Model Blackhawk Bisley; 5 1/2-inch barrel; case: Starline; overall loaded length (inches): 1.630; maximum case length: 1.285 inches; trim-to length: 1.275 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 200 | Hornady HP-XTP | 27.0 | 1570 | |
| 200 | Hornady HP-XTP | 28.0 | 1635 | |
| 200 | Hornady HP-XTP | 29.0 | 1706 | |
| 210 | Winchester Silvertip HP | 28.5 | 1646 | |
| 240 | Hornady HP-XTP | 23.0 | 1402 | |
| 240 | Hornady HP-XTP | 24.0 | 1440 | |
| 240 | Hornady HP-XTP | 25.0 | 1491 | |
| 240 | Speer Gold Dot HP | 23.0 | 1389 | |
| 240 | Speer Gold Dot HP | 24.0 | 1423 | |
| 240 | Speer Gold Dot HP | 25.0 | 1480 | |
| 240 | Nosler HP | 23.0 | 1415 | |
| 240 | Nosler HP | 24.0 | 1454 | |
| 240 | Nosler HP | 25.0 | 1502 | |
| 250 | Mt. Baldy Keith cast | 24.0 | 1270 | |
| 250 | Mt. Baldy Keith cast | 25.0 | 1315 | |
| 250 | Mt. Baldy Keith cast | 25.0 | 1339 | |
| 300 | Hornady HP-XTP | 20.0 | 1321 | cartridge overall loaded length is 1.735 inches |
| 300 | Hornady HP-XTP | 21.0 | 1397 | cartridge overall loaded length is 1.735 inches |
| 300 | Hornady HP-XTP | 22.0 | 1434 | cartridge overall loaded length is 1.735 inches |
| 270 | Speer Gold Dot SP | 20.0 | 1157 | |
| 270 | Speer Gold Dot SP | 21.0 | 1201 | |
| 270 | Speer Gold Dot SP | 22.0 | 1261 | |
| 310 | O.T. TrueShot WNFP | 20.0 | 1468 | |
| 310 | O.T. TrueShot WNFP | 21.0 | 1489 | |
| 310 | O.T. TrueShot WNFP | 22.0 | 1521 | |
primer: CCI 300; case: Starline. Loads were fired from a 7 1/2-inch barreled Ruger Bisley. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 250 | Lyman/Keith 429421 (original) | 24.5 | 1465 | overall loaded length (inches): 1.706 |
| in a Ruger Blackhawk (Flattop) Ruger Blackhawk (Flattop), 7 1/2-inch barrel. Starline cases used for all loads. CCI 350 Magnum primers used only with H-110 powder. All other loads used CCI 300 primers. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 210 | Winchester Silvertip HP | 28.5 | 2036 | 75-yard group (inches): 1.20; primer: CCI 300 |
| 240 | Nosler JHP | 25.0 | 1812 | 75-yard group (inches): .90; primer: CCI 300 |
| 270 | Speer Deep Curl/GD | 22.0 | 1566 | 75-yard group (inches): 1.35; primer: CCI 300 |
| 300 | Speer PSP/Deep Curl | 22.0 | 1507 | 75-yard group (inches): 1.30; primer: CCI 300 |
| in a Ruger M77 18 1/2-inch barrel. Maximum overall cartridge length of 1.610 inches and a SAAMI maximum pressure of 36,000 psi. Starline cases were used throughout. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 250 | Lyman/Keith 429421 (original) | 24.5 | 1420 | overall loaded length (inches): 1.706 |
| in a Smith & Wesson Model 29-5 Smith & Wesson Model 29-5, 6-inch barrel. Starline cases used for all loads. CCI 350 Magnum primers used only with H-110 powder. All other loads used CCI 300 primers. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 240 | Sierra Jacketed Hollow Cavity | 23.0 | 1043 | case: Federal; overall loaded length (inches): 1.600; group (inches): 4.10; 4 shots in 2.78 |
| Lightweight Loads Velocities were recorded 10 feet in front of the muzzle of the 4-inch barrel of a Smith & Wesson 329PD revolver. CCI 300 primers were used with all loads. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 240 | 24.0 | 1462 | ||
| 270 | 21.0 | 1271 | ||
| 300 | 21.0 | 1225 | ||
Magnum strength primers used exclusively. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 300 | 24.0 | 1207 | ||
This load is for Ruger or Freedom Arms revolvers only. Not for use in the Ruger New Vaquero. Magnum strength primers used exclusively. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 360 | Oregon Trail TrueShot WNFP-GC | 22.0 | 1298 | overall loaded length (inches): 1.675 |
| 360 | Oregon Trail TrueShot WNFP-GC | 23.0 | 1351 | overall loaded length (inches): 1.675 |
| 360 | Oregon Trail TrueShot WNFP-GC | 24.0 | 1404 | overall loaded length (inches): 1.675 |
| 360 | Oregon Trail TrueShot WNFP-GC | 25.0 | 1430 | overall loaded length (inches): 1.675 |
| for Ruger Redhawk Revolvers ONLY A Ruger Redhawk .45 Colt with a one-in-16-inch twist. 7 1/2-inch barrel was used to test-fire these loads. Starline cases and CCI 350 Large Pistol Magnum primers were used throughout. Loads approach 50,000 psi. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 360 | TrueShot WNFP-GC | 23.0 | 1278 | primer: CCI 300 |
| 360 | TrueShot WNFP-GC | 24.0 | 1298 | primer: CCI 300 |
| Ruger +P (32,000 CUP) (Oregon Trail Cast Bullet Loads) (For "44 Frame" Blackhawks and Redhawks only); Ruger New Model Blackhawk Bisley; 5 1/2-inch barrel; case: Starline; overall loaded length (inches): 1.675; maximum case length: 1.285 inches; trim-to length: 1.275 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 260 | Speer HP | 31.0 | 1665 | OAL: 1.670" |
| 300 | Speer UCSP | 29.5 | 1535 | OAL: 1.760" |
| 300 | Speer GDHP | 31.0 | 1740 | OAL: 1.740"; compressed load |
| Alliant Power Pro Data Primer: Fed 205; case: Federal; NOTE: All loads are maximum. Reduce by 10% to establish a starting charge weight. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 360 | TrueShot WNFP-GC | 27.0 | 1500 | |
| 360 | TrueShot WNFP-GC | 28.5 | 1588 | |
| Oregon Trail Cast Bullet Loads Freedom Arms Model 83; 7 1/2-inch barrel; primer: Remington 7 1/2 BR; case: Starline; overall loaded length (inches): 1.760; maximum case length: 1.383 inches; trim-to length: 1.373 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 260 | Nosler Partition HP | 29.0 | 1468 | |
| 260 | Nosler Partition HP | 30.0 | 1540 | |
| 260 | Nosler Partition HP | 31.0 | 1555 | |
| 300 | Speer Gold Dot HP | 29.0 | 1450 | |
| 300 | Speer Gold Dot HP | 30.0 | 1522 | |
| 300 | Speer Gold Dot HP | 31.0 | 1552 | |
| 360 | O.T. TrueShot WNFP | 26.0 | 1473 | |
| 360 | O.T. TrueShot WNFP | 27.0 | 1500 | |
| 360 | O.T. TrueShot WNFP | 28.0 | 1556 | |
| 360 | O.T. TrueShot WNFP | 28.5 | 1588 | |
primer: Remington 7 1/2; case: Starline. A Freedom Arms Model 83 with a 7 1/2-inch barrel was used to fire the .454 Casull loads. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 260 | Speer HP | 36.0 | 1835 | OAL: 2.090" |
| 300 | Speer UCSP | 28.0 | 1610 | OAL: 2.170" |
| 300 | Speer GDHP | 38.0 | 1930 | OAL: 2.150" |
| Alliant Power Pro Data Primer: Fed 210; case: Federal; NOTE: All loads are maximum. Reduce by 10% to establish a starting charge weight. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 275 | Speer GDHP | 38.0 | 1910 | OAL: 1.640"; compressed load |
| 325 | Speer GDSP | 29.5 | 1620 | OAL: 1.650"; compressed load |
| 400 | Speer GDSP | 24.2 | 1370 | OAL: 1.650"; compressed load |
| Alliant Power Pro Data Primer: Fed 150; case: Ruger; NOTE: All loads are maximum. Reduce by 10% to establish a starting charge weight. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
| 355 | TrueShot WNFP-GC | 29.0 | 1432 | primer: CCI 300 |
| Oregon Trail Cast Bullet Loads Freedom Arms Model 757; 6-inch barrel; case: Hornady; overall loaded length (inches): 1.665; maximum case length: 1.285 inches; trim-to length: 1.275 inches. | |||||
| Wt. | Bullet | Charge | Velocity (FPS) | Remarks | |
|---|---|---|---|---|---|
| 350 | Speer UCSP | 49.0 | 2000 | |
| Alliant Reloaders Guide 2008 primer: Fed 215; case: Starline; OAL: 2.250"; NOTE: All loads are maximum. Reduce by 10% to establish a starting charge weight. Alliant Pistol/Revolver Load Data | |||||
